Power supply voltage 230 V AC
Maximum AC-1 load current 6 A
Operating threshold - adjustable 3÷2000 Lx
Delay of operation less than 1 s
Frequency of microwave radiation 5,8 GHz
Maximum radiation power 10 mW
Detection field 180°
The receiver activation time - adjustable 10±3 s ÷ 12±1 min.
Motion detection 0,6÷1,5 m/s
Horizontal detection field 0°÷180°
Promień detekcji (regulowany, dla h 1÷1,8 m) 1÷8 m
Sensor mounting height 1,0÷1,8 m
Type of detection microwave
Terminal pluggable terminal blocks 1,0 mm²
Tightening torque 0,25 Nm
Power consumption 0,9 W
Working temperature -25 ÷ 50 °C
Dimensions zewnętrzne: 80×80×48 mm; wpust: Ø55 mm, h: 33 mm; otwór montażowy: Ø60mm
Assembly podtynkowy
Ingress Protection Marking IP20
