Power supply voltage 230 V AC
Power supply tolerance -10 ÷ 10 %
Maximum AC-1 load current 16 A
The executive element relay
Contact configuration 1 × NO
Separation of the contact YES
Operating threshold - adjustable 2 ÷ 1000 Lx
Operating threshold - set ok. 7 Lx
Hysteresis ok. 15 Lx
Delay of switching on ok. 10 s
Delay of tripping operation ok. 20 s
The degree of probe protection IP65
Photosensitive element external probe Ø 10 mm
Terminal pluggable terminal blocks 2,5 mm²
Tightening torque 0,4 Nm
Power consumption 0,56 W
Working temperature -25 ÷ 50 °C
Dimensions 1 module (18 mm)
Assembly on rail 35 mm
Ingress Protection Marking IP20
