Power supply voltage 230 V AC
Maximum AC-1 load current 5 A
Turn-off time 10 s±3 s ÷ 15 min. (±2 min.)
Twilight activation threshold 3÷2000 Lx
Motion detection 0,6÷1,5 m/s
Horizontal detection field 0°÷180°
Vertical detection field 0°÷45°
Maximum adjustable detection radius (h: 2.5 m, Temp. 24 12 m
Sensor mounting height 1,8÷2,5 m
Head rotation range - horizontally / vertically 60°/180°
Type of detection infrared
Terminal pluggable terminal blocks 1,5 mm²
Tightening torque 0,3 Nm
Power consumption 0,5 W
Working temperature -20÷40°C
Dimensions head vertically spread: S80 × W52 × G120 mm; horizontal folded head: S80 × W52 × G95 mm
Assembly on wall
Ingress Protection Marking IP65 - hermetic
